HTRV - Cuptor tubular vertical pentru temperaturi înalte

The Carbolite high temperature tube furnaces HTRH can be used horizontally up to 1800 °C.

The high-grade insulation materials guarantee low energy consumption and high heating rates due to their low thermal conductivity. The insulation and molybdenum disilicide (MoSi₂) heating elements are installed in the rectangular housing. The heating elements are vertically hanging and can be replaced easily. At higher temperatures and in the presence of oxygen, MoSi₂ develops an oxide (SiO₂) layer, which protects the heating elements against further thermal or chemical corrosion.

Three-zone tube furnaces (HTRH-3) can achieve better temperature uniformity than single-zone versions. In these models each zone is equipped with a dedicated thermocouple and controller, which is especially useful to preheat gases required for reactions inside the system.

The HTRH tube furnaces do not include an integral work tube. The work tube must be selected as an additional item. The work tube length is dependent on the application and will vary if used with or without modified atmosphere or vacuum.

recoacere, carbonizare, creştere cristale, descompunere, degazificare, deshidratare, călire, metal injection moulding (MIM), pyrolyses, rapid prototyping, sintering, sublimation, sinteză, maleabilizare

• 1800 °C temperatura maximă de operare
• Sistem de control programabil, model EPC3016P1
• Protecție la supra-încălzire
• Optimised for vertical usage
• Accepts work tubes with outer diameters up to 100 mm for use with modified atmosphere
• Accepts work tubes with outer diameters up to 200 mm for use in air
• Heated lengths of 100, 250 or 500 mm
• High grade type B thermocouple
• Low thermal mass ceramic fibre insulation
• Vertically hanging, high quality MoSi2 heating elements
• Rectangular housing with holes for convection cooling
• Furnace comes with separate control box with 3 m cable, plug and socket
• Conexiune Ethernet

• Gamă de sisteme de control digitale sofisticate, fiind diponibile opțional programe cu segmente multiple și înregistrare de date cu opțiune de transmitere digitală - mai multe înformații despre sistemele de control disponibile
• A range of additional work tubes is available in a variety of materials
• prizele de izolație și scuturile de radiație sunt recomandate pentru cuptoare cu tub vertical cu temperatură ridicată pentru a preveni pierderea de căldură și a îmbunătăți uniformitatea
• ansamblele de vidare şi atmosferă modificată sunt disponibile - Mai multe informaţii
• Vacuum packages with a choice of rotary vane pump or turbomolecular pump are available for furnaces with tube inner diameters of 60 mm and above
• 'L' stand for convenient usage
• Oxygen sensor for inert gas packages
• Gas packages with manual or automatic valve for up to 3 gases
• 6 m long cable between furnace body and control box with plug and socket
• Laboratory Gas Safety System for safe use with hydrogen above 750 °C
