The unique feature of the LHT high temperature laboratory furnace series is a compact design, making it the perfect tool for laboratories in research and development environments.
The cylindrical usable space of the laboratory furnace is surrounded by the heating elements and insulation material. The heated chamber is integrated into the water cooled vessel. As a result of the small volume, the LHT is ideal for small samples and requires minimal operating space.
The system is supported by a single frame platform which supports the furnace and electronic cabinet containing the software controls. Casters are attached to the supporting platform, which allows the whole system to move easily. For universities and industrial research laboratories, the LHT series is a perfect fit for such operating areas.
The small overall dimensions and simple operation result in a cost effective system without any performance loss in temperature uniformity or atmospheric quality. Additionally, the cylindrical design is best suited for overpressure heat treatment processes. Upon request, the system can be equipped with a suitable locking device and all necessary equipment for safe overpressure operations up to 100 bar.
The metallic LHT models are based on heating elements and radiation shields constructed of tungsten or molybdenum for a maximum temperature of 2200 °C and 1600 °C, respectively. The radiation shields serve to insulate the heat of the heating elements from the water cooled vessel. The metallic LHT systems provide the highest possible atmospheric purity and best final vacuum level. With a turbomolecular pump in combination with a pre-pump, the working vacuum can reach the high vacuum region. An ultra high vacuum configuration is possible upon request.
Toepassingsvoorbeelden
gloeien, solderen, carbonisatie, keramisch injectie vormgieten (CIM), ontbinden, ontgassen, drogen, verharding, metaal injectie vormgieten (MIM), pyrolyse, Quenching, rapid prototyping, siliconisering, sinteren, soldering, sublimering, synthese, temperen
Standaard functies
- Compact design suited for laboratories
- Best possible vacuum
- Vacuum level < 5 x 10-6 mbar
- Partial pressure 10 – 1000 mbar
- Overpressure operation up to 100 bar possible
- Hydrogen partial pressure operation on demand
- Precisely controlled vacuum pumping speeds appropriate for use with powders
- Data registratie voor kwaliteitsbeheer
Laboratorium oven, metalen isolatie (LHTM/W) Binnenkant van de LHT-laboratoriumoven bekijken
- Water cooled vessel
- Heating elements
- Top cover, manually operated
- Thermocouple
- Radiation shields at the top
- Radiation shields at the mantle
- Short circuit ring
The LHTM and LHTW are both constructed of metallic materials and 9 radiation shields. It has a single heating zone that covers the mantle of the cylindrical vessel. The mantle heater is designed for the highest stability. Two different heating elements are available. The standard heating elements consists of several molybdenum sheets, and upon request, a mesh heater is also available. The sample can be protected by a retort that further improves temperature uniformity. With the adaption of a high vacuum system, the best final vacuum is available.
Software operation is available with manual or automated controls. For the manual version, all valves and pumps are operated by simple push buttons at the user panel with a rotameter used to adjust gas flow. The automated software is operated via a touch panel interface. Mass flow controllers are used to regulate the gas flow. Data logging is possible for both manual and automated operation.
View inside LHT
Laboratorium oven, metalen isolatie (LHTM/W) Voorbeelden
LHTM/W 200-300 Smart
LHTW 200-300/22-1G automatisch tot 2200°C met optioneel waterstof pakket
Laboratorium oven, metalen isolatie (LHTM/W) Technische Gegevens
| Insulation material | Afmetingen: Buiten H x B x D (mm) | Transport weight (kg) | Usable space | Volume (l) | Ø x H, usable space without retort (mm) | Ø x H, usable space with retort (mm) | Thermal values | Tmax vacuum (°C) | Tmax atmospheric pressure (°C) | -Delta-T, between 500°C and 2200°C (K) according to DIN 17052 | Max. heat-up rate (K/min) | Cooling time (h) | Connecting values | Vermogen (kW) | Voltage (V) | Current (A) | Series fuse (A) | Vacuum (option) | Leakage rate - clean, cold and empty (mbar l/s) | Vacuum range depending on the pumping unit | Cooling water required | Flow (l/min) | Max. inlet temperature (°C) | Gas supply | Nitrogen or Argon flow, others on request (l/h) | Controller | Manual operation | Automatic operation | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LHTM 100-200/16-1G | Molybdenum | 1800 x 1900 x 1000 | 800 | |
1.5 | 100 x 200 | 90 x 200 | |
1600 | 1600 | ± 10 | 10 | 2.5 | |
22 | 400 (3P) | 3 x 55 | 3 x 63 | |
< 5x10-3 | rough, fine, high or ultra high vacuum | |
30 | 23 | |
50-500 | |
TP1200 touch panel | TP1900 touch panel, Siemens S7-1500 PLC |
| LHTM 200-300/16-1G | Molybdenum | 1800 x 1900 x 1000 | 950 | |
10 | 200 x 300 | 180 x 300 | |
1600 | 1600 | ± 10 | 10 | 4 | |
45 | 400 (3P) | 3 x 65 | 3 x 80 | |
< 5x10-3 | rough, fine, high or ultra high vacuum | |
50 | 23 | |
50-500 | |
TP1200 touch panel | TP1900 touch panel, Siemens S7-1500 PLC |
| LHTW 100-200/22-1G | Tungsten | 1800 x 1900 x 1000 | 850 | |
1.5 | 100 x 200 | 90 x 200 | |
2200 | 2200 | ± 10 | 10 | 3 | |
45 | 400 (3P) | 3 x 112.5 | 3 x 160 | |
< 5x10-3 | rough, fine, high or ultra high vacuum | |
50 | 23 | |
50-500 | |
TP1200 touch panel | TP1900 touch panel, Siemens S7-1500 PLC |
| LHTW 200-300/22-1G | Tungsten | 1800 x 1900 x 1000 | 1000 | |
10 | 200 x 300 | 180 x 300 | |
2200 | 2200 | ± 10 | 10 | 5 | |
90 | 400 (3P) | 3 x 130 | 3 x 160 | |
< 5x10-3 | rough, fine, high or ultra high vacuum | |
75 | 23 | |
50-500 | |
TP1200 touch panel | TP1900 touch panel, Siemens S7-1500 PLC |
