HTRH - Cuptor tubular orizontal pentru temperaturi înalte

The Carbolite high temperature tube furnaces HTRH can be used horizontally up to 1800 °C.

The high-grade insulation materials guarantee low energy consumption and high heating rates due to their low thermal conductivity. The insulation and molybdenum disilicide (MoSi₂) heating elements are installed in the rectangular housing. The heating elements are vertically hanging and can be replaced easily. At higher temperatures and in the presence of oxygen, MoSi₂ develops an oxide (SiO₂) layer, which protects the heating elements against further thermal or chemical corrosion.

Three-zone tube furnaces (HTRH-3) can achieve better temperature uniformity than single-zone versions. In these models each zone is equipped with a dedicated thermocouple and controller, which is especially useful to preheat gases required for reactions inside the system.

The HTRH tube furnaces do not include an integral work tube. The work tube must be selected as an additional item. The work tube length is dependent on the application and will vary if used with or without modified atmosphere or vacuum.

CIM, CVD, MIM, ageing, recoacere, brazing, calcinare, catalyst research, coating, degazificare, deshidratare, fuel cell testing, călire, miniplants, pyrolysis, sintering, soldering, sublimation, sinteză, maleabilizare, thermocouple calibration

• 1800 °C temperatura maximă de operare
• Programmable temperature controller with 24 segments: HTRH fitted with EPC3016P1, HTRH-3 fitted with CC-T1
• Protecție la supra-încălzire
• Accepts work tubes with outer diameters up to 100 mm for use with modified atmosphere
• Accepts work tubes with outer diameters up to 200 mm for use in air
• Heated lengths of 100, 150, 250, 300, 600 or 900 mm
• Low thermal mass ceramic fibre insulation
• High quality MoSi₂ heating elements in a vertical, hanging position
• Rectangular housing with holes for convection cooling
• Available with 1 - 3 heating zones
• Furnace comes with separate control box with 3 m cable, plug and socket
• Conexiune Ethernet

• Gamă de sisteme de control digitale sofisticate, fiind diponibile opțional programe cu segmente multiple și înregistrare de date cu opțiune de transmitere digitală - mai multe înformații despre sistemele de control disponibile
• A range of additional work tubes is available in a variety of materials
• prizele de izolație și scuturile de radiație sunt recomandate pentru cuptoare cu tub vertical cu temperatură ridicată pentru a preveni pierderea de căldură și a îmbunătăți uniformitatea
• ansamblele de vidare şi atmosferă modificată sunt disponibile - Mai multe informaţii
• Vacuum packages with a choice of rotary vane pump or turbomolecular pump are available for furnaces with tube inner diameters of 60 mm and above
• Oxygen sensor for inert gas packages
• Gas packages with manual or automatic valve for up to 3 gases
• 6 m long cable between furnace body and control box with plug and socket
